11CT
Inrush-withstand 3216 surface mount fuse with 10 A maximum rated current
RoHS-compliant
Pb free
Features
- High breaking capability by heat-resistant and high-strength ceramic body
- Reduced effect of external temperature by inner structure designing
- Prevention of external tension on element by flexible terminals
- Solderless construction
- Excellent inrush-withstanding capability and high reliability by wound-wire element
- Lower resistance compared to similar type fuses by inner structure designing
- Less susceptible to thermal effects during board mounting by element welded to terminals
Applications
- DC-DC converter
- IC tester
- PLC
- Actuator
- Automotive navigation system
- BMS
- Motor driver
- DC secondary circuit
- ECU
- OA equipment
- USB charger
- Intercom
- Battery pack
- Portable device
- Automotive electronics
- Multi-function printer
- Characteristic
Inrush-withstand
Representative pre-arcing time-current characteristics

Blueprint / Size
Detailed information
Please contact us if you require specifications outside the scope of those listed above.
