Please contact us if the following products do not meet your circuit protection requirements.

Contact
  • Catalog
  • Specification
  • White Paper
Product Name
Rated
Voltage
Rated
Current
Shape Characteristic Size Certification Application Documents
36CFA DC 600 V 63 mA - 3.15 A Surface mount type Quick-acting W3.6 mm × H3.6 mm × L11 mm
Automotive
New Energy
Security
Industrial
Lighting
Medical
Home Appliance
Information Communication
36CFA DC 425 V 4 A Surface mount type Quick-acting W3.6 mm × H3.6 mm × L11 mm
Automotive
New Energy
Security
Industrial
Lighting
Medical
Home Appliance
Information Communication
500VBL1030A AC 500 V
DC 500 V
5 A - 50 A Bolted connection type φ10 mm × L32 mm
Automotive
New Energy
DC450VPT2035 DC 450 V 100 A - 150 A Bolted connection type φ20 mm × L35 mm
Automotive
New Energy
DC450VPT2545 DC 450 V 180 A - 225 A Bolted connection type φ26 mm × L46 mm
Automotive
New Energy
DC450VPT3050 DC 450 V 250 A - 350 A Bolted connection type φ31 mm × L51 mm
Automotive
New Energy
DC500VBC625A DC 500 V 5 A - 35 A Bolted connection type φ6.35 mm × L24.6 mm
Automotive
New Energy
DC500VBI625C DC 500 V 5 A - 35 A Board mount type φ6.35 mm × L24.6 mm
Automotive
New Energy
DC500VPL1040A DC 500 V 40 A - 50 A Bolted connection type Quick-acting φ10 mm × L40 mm
Automotive
New Energy
SHV12 AC 500 V
DC 400 V
100 mA - 6.3 A Cartridge type Inrush-withstand φ5.2 mm × L20 mm
New Energy
Industrial
SHV12 AC 400 V
DC 250 V
100 mA - 6.3 A Cartridge type Inrush-withstand φ5.2 mm × L20 mm
New Energy
Industrial
SHV12 AC 400 V
DC 400 V
1 A - 6.3 A Cartridge type Inrush-withstand φ5.2 mm × L20 mm
New Energy
Industrial
